I gradi delle punte per sega in carburo di tungsteno:
| Gradi di grana fine | ||||
| Grado | Densità | T.R.S | Durezza | Performance &application recommended. |
| G/CM3 | MPa | HRA | ||
| YG6X | 14.7 | 1900 | 92.5 | Legno duro, MDF, HDF, compositi di alluminio e plastica e materiali sottili. metalli non ferrosi. |
| YG8A | 14.5 | 2200 | 91 | Hard wood, veneer board, PCB, PVC & metals. |
| YG8X | 14.4 | 2420 | 92 | Acciaio al carbonio, acciaio refrattario, acciaio al manganese e acciaio inossidabile. acciaio. |
| YG2T | 14.7 | 2000 | 91.2 | General and hard wood. |
| YG10X | 14.5 | 3600 | 91.5 | Hard wood, wood-based panels, chilled cast iron, fiberglass, aluminum, copper. |
| YG10T | 14.9 | 1890 | 91.5 | General and hard wood. |
| Gradi di grana media e grossa | ||||
| YG6 | 14.9 | 2100 | 90 | Legno duro, legno originale, profilato di alluminio, asta di ottone e ghisa. |
| YG8 | 14.7 | 2400 | 89.5 | Dry wood, soft wood, aluminum and brass, graphite and grass. |
| YG8C | 14.7 | 2450 | 88.5 | Legno tenero e secco, legno generico con nodi sciolti, materiale artificiale marble, ceramics and grass. |
| YG9C | 14.4 | 2600 | 87 | Per la scortecciatura e il taglio di legno congelato, legno tenero e legno originale. |
| YG11C | 14.1 | 2200 | 90.5 | Legno duro, metallo non ferroso, granito e marmo. |
| YG15C | 14 | 2700 | 86.5 | Per la scortecciatura e il taglio di legno congelato, legno tenero e legno originale. |
Applicazioni delle punte per sega in carburo di tungsteno:
Dettagli sulle punte per sega in carburo di tungsteno:
FAQ for tungsten carbide saw tips:
Q1: What are tungsten carbide saw tips?
A: Tungsten carbide saw tips are WC-Co hard alloy cutting inserts brazed on circular saw blades. They feature high hardness and wear resistance for cutting wood, MDF, plywood, aluminum, copper, plastic, composite panels, mild steel and thin stainless steel tubes.
Q2: What is the hardness of tungsten carbide saw tips?
A: The hardness of carbide saw tips typically ranges from 87 HRA to 93 HRA, depending on cobalt content, grain size, and application requirements.
Q3: Can tungsten carbide saw tips be customized?
A: Yes. As a professional manufacturer of carbide saw tips, we offer the following customized services:
(1) Custom dimensions.
(2) Special tooth geometries.
(3) Various chamfer designs.
(4) Customized carbide grades.
(5) OEM tungsten carbide tips and ODM tungsten carbide tips production services.
We produce custom tungsten carbide saw tips based on customer drawings. Send us your drawings to get quotes and samples.
Q4: Which grade for wood cutting?
A: Clean soft wood, veneer, MDF: YG6X; Hardwood, lumber with nails & sand: YG8.
Q5: Which grade for aluminum, copper, acrylic cutting?
A: YG10X extra-fine grain with polished edges, which greatly reduces aluminum adhesion and delivers burr-free mirror cutting surface.
Q6: What sizes of carbide saw tips are available?
A: (1) Thickness: 1.0 mm to 10 mm.
(2) Width: 2 mm to 25 mm.
(3) Length: 5 mm to 50 mm.
Q7: What is your minimum order quantity?
A: Standard stock carbide saw tips: MOQ 1 kg.
Custom non-standard carbide saw tips: MOQ 5–10 kgs.
Q8: What are the lead times for stock and customized orders?
A: In-stock standard carbide saw tips: 2–3 working days lead time.
Custom finished carbide saw tips: 10–25 working days lead time.
Vi preghiamo di inviarci richieste di quotazioni e campioni gratuiti da testare:
